9V36
CLAMP RING PUMP FLUID-O-TECH 200 L/H
The rotary vane pump, along with the motor that allows it to rotate at high speed, is the beating heart of every professional coffee machine. Its job is to increase the pressure of the water moving within the machine's hydraulic circuit, allowing the water to reach a pressure of 9 bar, ideal for achieving the best espresso extraction. To maintain its constant functionality over time, it is necessary to prevent impurities in the water (sand, limestone) from reaching the internal graphite vanes. To protect the pump, we recommend installing a wound wire filter (code 9V905) upstream of the machine and a mechanical filter (code 8W56116-P) on the pump. This pump is equipped with a balanced bypass for regulating the operating pressure. For connection to the machine's internal pipes, a 3/8" GAS fitting is available on the DVG website: code 9R10-P.. The pump is compact: total length 99mm, body length 86mm. The serial code identifying the model, date of manufacture, and all information about the pump is printed on the rectangular label at the bottom of the pump.
If the label has been removed, the warranty will not be recognized.
